Airless Striping Applications

Linelazer 3400

The compact lightweight one gun Linelazer 3400 is the ideal professional striper for smaller jobs such as maintenance work and small vehicle parking areas.  Features include parking brake, swivelling front wheel and comfortable handle bars. Weighing only 65 kgs and with tall wheels the Linelazer 3400 is certainly easy to handle and offers excellent stability for linemarking.

Operating at 230bar  (3300 psi)  maximum  pressure the Linelazer has more than enough power to evenly atomise today’s  demanding coatings.  Heavy duty gear system and maintenance free clutch combined with endurance pump technology allowing full compatibility with waterborne, solvent based and chlorinated rubber type paints.

Electronic pressure control and operator level controls give easy operation for operator “on the fly” adjustments and if need be emergency shut off. An even pressure, essential for line striping, is maintained via the electronic pressure control giving an extremely fast response time. This helps to eliminate pressure fluctuations and deadbands.

Linelazer IV 3900 & 5900

Both the Linelazer 3900 and 5900 with new and improved technologies offer precise and consistent lines. Ideal for car parks, street marking and many other applications. Features include Easy hose wrap , flow through filter and A.V.R.S. (Advanced Vibration Reduction System). A.V.R.S. reduces vibrations up to 60% with an exclusive pump sprayer mounting system and new single gun bar holder. This combined with the option of rear mounted gun simply gives better line quality  improving both straightness and consistency.

The GMAX II larger Endurance pumping systems give more flow leading to faster striping and higher productivity. Being an airless machine does not restrict solely to line marking they can also be used for stenciling and general painting. No tools are required for quick gun removal with the one piece extruded aluminium gun mount perfect and consistent gun positioning is possible every time.

With a backlit dashboard for better visibility at night or in low light conditions, 3 position height adjustable dashboard, an accessory plug and a more comfortable handle bar design the Linelazer  is made easier to use and with less lateral movement leads to straighter and more consistent lines.



Linelazer IV 200 HS

With the highest flow rate of the range and powered by a very heavy duty hydraulic system the Linelazer IV 200 HS is the workhorse of the range.  Ideally suited to working in large car parks, airports or for street marking, offering an unmatched production rate and trouble free operation. Features include easy hose wrap , flow through filter, Quick select gun selector, Front swivel wheel with Fat Track system and A.V.R.S. (Advanced Vibration Reduction System). A.V.R.S. reduces vibrations up to 60% with an exclusive pump sprayer mounting system and new single gun bar holder. This all combines to give straighter, sharper, more precise and more consistent lines.

The natural heat generated by a hydraulic system  and the need to keep a hydraulic system cool both for long life and trouble free operation has lead to an increase in reservoir capacity of 20% and a new fan design giving 70% more flow ensuring the system is kept cool and runs at optimal temperatures. The ABS belt cover is easy to clean won’t bend, crack or rust now covers the perfectly aligned belt, which not only offer a better power transfer efficiency also has no need for adjustment and has an extended life.

The largest pump in the Linelazer IV range with the highest flow features the Chromex piston rod which can be up to 4 times harder than chrome to extend serviceable life. As you would expect the Chromex rod is fully compatible with waterborne, solvent based or chlorinated rubber type paints. With the ability to  support a 0.045” (45 thou) tip on one gun or 0.033”(33 thou) tip on two guns the Linelazer IV 200HS  proves itself  as the  true workhorse of the range.



Technical Specifications

Accessories

Striping Tips

LineLazer tips are especially designed to create clean, lazer sharp lines with no fuzzy edges. Line width is measured with the tip positioned 15cm above the surface. Width can be adjusted by lowering or raising the gun.

To order LL5-XXX. Replace the XXX with the chosen tip size.

Make sure that the flow rate of the tip is within the performance ability of the striper

Spray Equipment Specialists

Sales ~ Hire ~ Repairs

Trade Spray Services Ltd Unit 7 Oasthouse Way Orpington, Kent BR5 3PT

Registered in England 5396692



LineLazer

3400

LineLazer

IV 3900

LineLazer

IV 5900

LineLazer

IV 200HS

Maximum Tip Size 1 Gun

0.027”

0.035”

0.043”

0.045”

Maximum Tip Size 2 Guns

X

0.025”

0.029”

0.033”

Maximum Fluid Flow

2.8 Ltr / Min

4.7 Ltr / Min

6.0 Ltr / Min

7.5 Ltr / Min

Output Difference

>

>66%               More than 3400

>28%               More than 3900

>25%         More than 5900

Maximum Pressure

230 bar

230 bar

230 bar

230 bar

Honda Engine Type

4.0 HP (3 Kw)

4.0 HP (3Kw)

5.5 HP (4 .1 Kw)

5.5 HP (4.1 Kw)

Fuel Tank Capacity

2.5 Ltr

2.5 Ltr

3.6 Ltr

3.6 Ltr

Weight

65 Kg

96 Kg

105 Kg

125 Kg

Dimensions in cm (WxHxL)

81 x 162 x 155

81 x 102 x 165

81 x 102 x 165

81 x 102 x 165

Km/H 10cm Line @ 300 microns (1)

6.5

9.0

11.5

16.0

245225

Striping Hose With Nickel Fittings 3/8” x 15 Mtr (230 bar)

277062

64cm Line Pointer System

277061

High Output LED Light

248157

Flexplus striping gun Mounted with Handtite guard  and LL5319 Tip

243161

Handtite Guard 7/8”

248393

60 Ltr Hopper Kit with Insulated rim

249081

Adjustable Spray Shield kit

2440xx

Easy Out Pump Filters 30(grey), 60(black), 100(blue) or 200(red) mesh

249187

Field Tyres, Wide low pressure turf tyres

287553

2nd Gun Kit for LineLazer IV Includes LL5319 + 286517

Line Width

0.013 “

0.015”

0.017”

0.019”

0.021”

0.023”

0.025”

0.027”

0.029”

0.031”

0.033”

0.035”

0.039”

5 cm

213

215

217

219



















10 cm



315

317

319

321

323

325

327

329

331

333

335



15 cm





417

419

421

423

425

427

429

431



435



30 cm









621

623

625

627

629

631



635

639

Flow Rate Ltr / Min

0.69

0.91

1.17

1.47

1.79

2.15

2.54

2.96

3.42

4.42

4.98

6.18

7.51
